Final Drive
Application
Torque
(Nm)
Notes
Bevel box finisher
4 Nm
Fit new fixing(s) if loosened or removed
Bevel box oil drain plug
25 Nm
Fit new sealing washer(s)
Bevel box oil level plug
25 Nm
Fit new sealing washer(s)
Bevel box to swinging arm nuts
*
Fit new fixing(s) if loosened or removed
Bevel box to swinging arm stage
1
20 Nm
Bevel box to swinging arm stage
2
100 Nm
Cush drive bearing retaining plate
18 Nm
Fit new fixing(s) if loosened or removed
Final drive studs
56 Nm
Fit new if loosened or removed
Frame, Footrests, Control Plates and Engine Mountings
Application
Torque
(Nm)
Notes
Bank angle indicator
9 Nm
Bracket moulding
1.5 Nm
Control plates
25 Nm
Control plate mounting
25 Nm
Flyscreen (YJ1)
1 Nm
Flyscreen (YK1 YL1)
3 Nm
Flyscreen mounting
5 Nm
Footrest rubber inserts
6 Nm
Fit new fixing(s) if loosened or removed
Frame adjusters
*
See Engine - Installation
