1035
2. Align the connector to its socket on the ABS modulator such that the end of the
lever aligns with the lug on the socket.
1. Lever end
2. Lug
3. Release the lever by pushing it towards the front of the connector. At the same
time, push the connector into its socket until the lever is fully forward and locked
in position. An audible click can be heard when locked.
1. ABS modulator (shown removed for clarity)
2. Connector
3. Locking device
4. Lever
