Pinpoint Tests
ABS Warning Light ON (No DTCs Stored)
Fault Code
Possible cause
Action
ABS Warning Light
ON (No DTCs Stored)
ABS Ignition supply
fuse/circuit fault
Make sure ABS ECM connector
is secure.
Disconnect ABS ECM connector
and proceed to pinpoint test 1:
ABS Warning light circuit
fault
Refer to CAN Fault.
Pinpoint Tests
Test
Result
Action
1
Check cable and terminal integrity:
- ABS ECM connector pin 4
- ABS ECM connector pin 10
OK
Proceed to test 2
Faulty
Rectify fault, proceed
to test 3
2
Check cable continuity of the ABS
ignition supply circuit: With the
ignition 'ON', check voltage between:
- ABS ECM connector pin 4 and
ground pin 10
Voltage
greater than
10 V
Proceed to test 3
Voltage less
than 10 V
Locate and rectify
wiring fault, proceed
to test 3
3
Reconnect ABS ECM harness, clear fault
code and test ABS to verify fault cleared.
OK
Action complete -
quit test
Fault still
present
Contact Triumph
service
