1085
NOTICE
If the brake fluid reservoir is NOT to be removed, omit steps 4 to 6.
4. Release the fixings and remove the reservoir cap, reservoir cover and diaphragm seal.
5. Remove the sealing screw from the reservoir mounting fixing.
6. Loosen the mounting fixing.
7. Release the fixings, lift off the clamp and remove the front brake master cylinder.
1. Fixings
2. Clamp
3. Master cylinder
1. Sealing screw
2. Fixing
3. Brake fluid reservoir
