Brake Fluid Reservoir
2. Check the condition of the spigot seal in the reservoir. Replace if damaged.
3. Fit the reservoir onto the master cylinder spigot.
1. Reservoir
2. Master cylinder
3. Seal
4. Spigot
4. Check the two O-rings on the reservoir fixing. Replace if damaged.
5. Check the front brakes for correct operation and fluid leaks. Rectify as necessary.
6. Fit the reservoir fixing. Do not fully tighten at this stage.
7. Fit the master cylinder to the motorcycle (see Front Brake Master Cylinder -
Installation).
