Front Brake Master Cylinder-Installation
Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
To prevent paint damage, do not spill brake fluid onto any area of the bodywork.
Spilled brake fluid will damage paintwork.
1. Locate the front brake master cylinder to the handlebars and fit the clamp, do not
fully tighten at this stage.
When fitting the front brake master cylinder, care must be taken to avoid trapping
switch housing harness between handlebar and reservoir clamp.
2. Align the straight edge on the clamp to the alignment mark on the handlebar (as
shown in the illustration below) and tighten the fixings (upper one first) to 8 Nm.
