Triumph Rocket 3 GT 2021 - Page 1129

1091
3. If loosened, tighten the brake fluid reservoir fixing to 25 Nm.
4. If removed fit the bleed screw and tighten to 6 Nm.
1. Bleed screw
2. Fixing
3. Brake fluid reservoir
5. Incorporating new sealing washers connect the brake hose to the master cylinder and
tighten the union bolt to 25 Nm.
1. Alignment mark
2. Straight edge
3. Clamp
