6. While pressing down on the anti-rattle spring, remove the brake pad retaining pin
from the left hand side.
1. Clip
2. Anti-rattle spring
3. Brake pad retaining pin
7. Remove the anti-rattle spring.
In the following operation, never lever directly against the disc, caliper or pad lining
material. Always use a levering tool made from a soft material that will not cause
damage to the load bearing surfaces.
Brake fluid will be displaced as the caliper pistons are compressed. To prevent body
damage, ensure that the displaced fluid does not come into contact with any part of
the bodywork.
