1106
5. Release the fixings and remove the cush drive outer. Discard the fixings.
1. Fixings
2. Cush drive outer
NOTICE
Note there is a flat washer between the brake disc and the cush drive outer for
installation.
Note there is a wave washer between the head of the fixings and the brake disc for
installation.
1. Fixing
2. Wavy washer
3. Brake disc
4. Flat washer
5. Cush drive outer
