5. Attach the rear wheel speed sensor connector to the hugger.
6. Position the hugger to the swinging arm. Make sure the left hand fixing hole aligns
with the harness guide fixing hole.
7. Fit the new fixings and tighten to 3 Nm.
1. Fixings
2. Connector
3. Hugger
8. Tighten the harness guide rear fixing to 3 Nm.
1. ABS wheel speed sensor connector
2. Fixing
3. Harness guide
