1129
3. Release the rear brake caliper mounting bolts and slide the caliper off the brake disc.
1. Caliper mounting bolts
4. Using a suitable a flat metal plate approximately 2 mm thick and 30 to 50 mm wide
(for example a gasket scraper) between the brake pads, pump the rear brake pedal
until the plate is held by the brake pads.
5. Disconnect the ABS modulator multiplug (see ABS Electrical Connectors).
6. Detach the fuel tank electrical connector from the anti-rotation moulding.
7. Remove and discard the fixings for the anti-rotation moulding.
