Triumph Rocket 3 GT 2021 - Page 1190

1152
5. Fit a new circlip into the groove on the opposite side of the wheel.
1. Circlip
2. Circlip groove
NOTICE
Circlip side: Install the seal until it's outer circumference just touches the circlip.
Chamfered side: Install the dust seal until the outer surface is positioned 3mm below
the surface of the wheel edge.
6. Lubricate and fit new dust seals to the front wheel. Lubricate the seal's knife-edge with
grease to NLGI 2 specification.
1. Dust seal
