Triumph Rocket 3 GT 2021 - Page 1208

1170
2. Detach the rear wheel speed sensor connector and remove the hugger.
1. Fixings
2. Connector
3. Hugger
NOTICE
Note the routing of the harnesses and brake line on the harness guide for installation.
3. Disconnect the rear light from the main harness.
4. Detach the rear brake hose from the harness guide.
