8. Fit the rear wheel spindle bolt.
9. Fit the rear wheel (see Rear Wheel - Installation).
10. Lower the motorcycle to the ground.
11. Tighten the rear wheel spindle bolt to 70 Nm.
Rear Bevel Box – Removal
Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
If fitting a new rear bevel box, remove the cush drive before removing it from the
swinging arm.
Perform the following operations:
• Seat - Removal
• Battery - Removal
• Rear Wheel - Removal
• If required, Cush Drive - Removal
1. Release the three fixings and detach the hugger from the swinging arm.
