6. Fit the cush drive rubber as noted for removal.
1. Cush drive rubber
2. Cush drive inner
3. Snap ring
4. Splines (bevel box)
5. Splines (cush drive)
6. Conical washer
7. Fit the cush drive outer to the rear bevel box and tighten the new fixings to 20 Nm.
1. Fixings
2. Cush drive outer
