2. Fit the rear wheel bearing retainer plate and tighten the fixings to 18 Nm.
1. Fixing
2. Bearing retaining plate
3. Bearing housing
4. Bearing
5. Dowel (one of five)
3. Fit the conical washer to the cush drive, as noted for removal.
4. Fit the snap ring to the groove in the cush drive splines.
5. Push fit the cush drive inner into the bevel box, make sure the snap ring also fits into
the groove of rear bevel box.
