1173
8. Release the fixing, detach the rear wheel speed sensor and position it aside. Discard
the fixing.
1. Fixing
2. Wheel speed sensor
9. Protect the swinging arm painted surfaces from damage, using a suitable self-
adhesive tape such as masking tape.
NOTICE
If a stud fitted to the rear bevel box becomes loose when the fixings are removed, a
new stud must be fitted.
