Triumph Rocket 3 GT 2021 - Page 1219

1181
1. Release the fixings and remove the swinging arm guard.
1. Fixings
2. Guard
NOTICE
The front upper fixing also secures the drive shaft cover.
Note the positions of the M6 x 20mm and M6 x 42mm fixings for installation.
2. Release the fixings and remove the starter motor cover.
1. Fixings M6 x 20mm
2. Fixing M6 x 42mm
3. Starter motor cover
