Perform the following operations:
1. Fit the drive shaft through the swinging arm and attach it to the torsional damper.
2. Fit the drive shaft cover between the transmission cover and the swinging arm.
1. Cover
3. Fit the starter motor cover tighten the M6 x 20 mm fixings to 9 Nm.
4. Tighten the M6 x 42 mm fixings to 7 Nm.
1. Fixings M6 x 20mm
2. Fixing M6 x 42mm
3. Starter motor cover
