3. Attach the ABS brake line bracket to the subframe and tighten the fixings to 9 Nm.
1. Fixings
2. ABS bracket
3. Fixings
4. Flanged sleeves
4. If removed, fit the hose to the temperature sensor as noted for removal.
5. Connect the electrical connector and position the temperature sensor with the hose
routed as for removal. Fit and tighten the fixing to 3 Nm.
1. Fixing
2. Electrical connector
3. Hose
4. Temperature sensor
