Triumph Rocket 3 GT 2021 - Page 1265

1227
NOTICE
Note the position of the split line on the gear change actuator arm with the alignment
mark on the gear change shaft for installation.
2. Release the fixing and disconnect the gear change actuator arm from the gear
change shaft.
3. Release the two fixings and detatch the left hand control plate from its mounting.
1. Fixing
2. Alignment mark
3. Split line
4. Actuator arm
1. Fixings
2. Left hand control plate
3. Control plate
mounting
