1228
NOTICE
If fitted, note the routing of the Triumph shift assist harness for installation.
4. If fitted, disconnect the Triumph shift assist from the main harness and remove the
control plate.
5. Release the three fixings and remove the control plate mounting.
1. Fixings
2. Control plate mounting
Left Hand Control Plate – Installation
1. Fit the control plate mounting to the crankcase and tighten the fixings to 25 Nm.
1. Fixings
2. Control plate mounting
