2. If fitted, route the Triumph shift assist harness as noted for removal and connect to
the main harness.
3. Fit the left hand control plate to its mounting and tighten the fixings to 36 Nm.
4. Fit the gear change actuator arm from to gear change shaft as noted for removal. Fit
the pinch bolt and tighten to 8 Nm.
5. If fitted with the Triumph shift assist, fit the starter motor cover tighten the M6 x20
mm fixings to 9 Nm.
