Triumph Rocket 3 GT 2021 - Page 1271

1233
5. Remove the side fixings for the radiator grille.
1. Fixing
2. Grille (left hand side)
NOTICE
The left hand upper fixing for the radiator grille also secures the bracket for the
radiator cap cover.
6. Remove the upper fixings and remove the grille.
1. Fixing
2. Grille (left hand side)
3. Bracket
