Radiator Cowl – Installation
Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
NOTICE
The left hand upper fixing for the radiator grille also secures the bracket for the
radiator cap cover.
1. Position the grille to the radiator, fit the upper fixings and tighten to 5 Nm.
1. Fixing
2. Grille (left hand side)
3. Bracket
