Triumph Rocket 3 GT 2021 - Page 1279

1241
2. Position the spigot to the grommet.
3. Press firmly to secure the panel.
4. Fit the oil filler tube clip and tighten the fixings to 1.5 Nm.
1. Fixings
2. Clip
3. Oil filler tube
1. Spigot
2. Grommet
3. Side panel locating
tank
4. Side panel locating slot
5. Seat lock hole
6. Seat lock
7. Oil filler tube hole
8. Oil filler tube
