Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
Right Hand Side Panel
1. Slide the side panel downwards while placing the side panel locating tang into the
side panel locating slot.
2. Position the spigots to the grommets.
3. Press firmly to secure the panel.
4. Grasp the panel and make sure that it is fully retained.
1. Spigots
2. Grommets
3. Side panel locating tang
4. Side panel locating slot
Left Hand Side Panel
1. Slide the side panel downwards while placing the side panel locating tang into the
side panel locating slot.
