Triumph Rocket 3 GT 2021 - Page 1288

1250
6. Attach the fuse box, 30A fuse and the connector to the battery box as noted for
removal.
1. Fuse box
2. 30A fuse
3. Connector
4. Battery box
7. Fit the rear subframe front bridge with its washers and fixings. Tighten the fixings to
12 Nm in the sequence shown.
Rear Subframe Front Bridge Tightening Sequence
