Triumph Rocket 3 GT 2021 - Page 1287

1249
4. Fit new left hand side fixings with the original washers and tighten to 6 Nm.
NOTICE
If the alarm panel is not positioned under the battery box correctly, the four fixings for
the base of the battery box will not have a threaded hole to fit into.
5. Position the alarm panel under the battery box as noted for removal, fit the four
fixings to the base of the battery box and tighten to 3 Nm.
1. Fixings
2. Battery box
1. Fixings
2. Washers
3. Battery box
