Battery Box – Installation
Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
1. Position the battery box to the frame.
NOTICE
The battery box right hand front fixing also secures the seat's right hand infill panel.
2. Fit the seat's right hand infill panel. Fit a new fixing with the original washer and
tighten to 6 Nm
3. Fit a new rear fixing with the original washer and tighten to 6 Nm.
1. Fixings
2. Washers
3. Right hand infill panel
4. Battery box
