NOTICE
The battery box right hand front fixing also secures the seat's right hand infill panel.
10. Remove the front fixing, washer and the seat's right hand infill panel. Discard the
fixing.
11. Remove the rear fixing and washer. Discard the fixing.
1. Fixings
2. Washers
3. Right hand infill panel
4. Battery box
12. Manoeuvre the battery box rearwards for removal
