NOTICE
Note the position of the alarm panel under the battery box for installation.
The four fixings in the base of the battery box are secured into the alarm panel. The
alarm panel will drop onto the swinging arm when the four fixings are removed.
8. Support the alarm panel under the battery box and remove the four fixings from the
base of the battery box. Position the alarm panel to one side.
1. Fixings
2. Battery box
9. Remove the left hand side fixings and washers. Discard the fixings.
1. Fixings
2. Washers
3. Battery box
