6. Release the fixings and washers, remove the rear subframe front bridge.
1. Harness clip
2. Fixings
3. Front bridge
7. Detach the fuse box, 30A fuse and the connector from the battery box.
1. Fuse box
2. 30A fuse
3. Connector
4. Battery box
