102
• Pivot the radiator lower surround and unscrew and remove the engine oil filter
using the Triumph service tool T3880313. Dispose of the old filter in an
environmentally friendly way.
1. Fixings
2. Bracket
3. Oil filter
4. Radiator lower surround
• Prefill the replacement engine oil filter with new engine oil.
• Apply a smear of clean engine oil to the sealing ring of the new engine oil filter.
Fit the engine oil filter and tighten to 10 Nm.
• Secure the radiator lower surround to its bracket and tighten the fixings to 4 Nm.
• After the engine oil has completely drained out, fit new sealing washers to the
three sump plugs. Fit and tighten the plugs to 30 Nm.
