Triumph Rocket 3 GT 2021 - Page 1300

1262
7. Disconnect the LF antenna from the main harness (rear mudguard removed for
clarity).
1. Connector
2. LF antenna
3. Harness
8. Remove the rear light centre fixing. 9. Loosen the rear light side fixings.
9. Loosen the rear light side fixings.
1. Rear light centre fixing
2. Rear light side fixing (right hand side shown)
3. Rear light
