Triumph Rocket 3 GT 2021 - Page 1301

1263
10. Remove the front fixings, washers and manouevre the mudguard rearwards for
removal.
1. Fixings (one on right hand side shown)
2. Washer
3. Rear mudguard
Rear Mudguard – Installation
Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
