Triumph Rocket 3 GT 2021 - Page 1312

1274
6. Tighten the rear subframe front pieces to 48 Nm.
1. Fixings
2. Front pieces (right hand side shown)
7. Fit the seat lock to the subframe rear bridge with its washers and
tighten the new fixings to 8 Nm.
8. Attach the harness clip to the rear subframe rear bridge.
1. Harness clip
2. Fixings
3. Seat lock
