Triumph Rocket 3 GT 2021 - Page 1313

1275
9. Attach the side panel bracket to the right hand side of the rear subframe. Tighten the
new fixing to 6 Nm
1. Fixing (harness removed for clarity)
2. Washer
3. Side panel bracket
10. Attach the outer battery box to the left hand side of the rear subframe. Tighten the
new fixings to 3 Nm.
1. Fixings
2. Washers
3. Outer battery box
