Instrument Wake-up Signal Overcurrent
Fault
Possible cause
Action
C1017
Instrument wake-up signal
overcurrent
Disconnect chassis ECM and proceed
to pinpoint test 1:
Pinpoint Tests
Test
Result
Action
1
Check cable and terminal integrity:
- Keyless ECM pin 9
- Instruments pin 32
OK
Disconnect instruments
connector and proceed to test
2
Faulty
Rectify fault, proceed to test 5
2
Check cable for short circuit:
- Keyless ECM pin 9 to ground
OK
Proceed to test 3
Short circuit
Locate and rectify wiring fault,
proceed to test 5
3
Check cable for short circuit:
- Keyless ECM pin 9 to Keyless
ECM pin 12
OK
Proceed to test 4
Short circuit
Locate and rectify wiring fault,
proceed to test 5
4
Check cable continuity:
- Keyless ECM pin 9 to instrument
pin 32
OK
Proceed to test 5
Open circuit
Locate and rectify wiring fault,
proceed to test 5
5
Reconnect harness, clear fault code
and run engine to verify fault
cleared
OK
Action complete – quit test
Fault still
present
Contact Triumph service
