Rear Light – Installation
Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
1. Position the rear light onto the rear mudguard and fit the captive nut.
2. Temporarily fit the rear light centre fixing. Do not fully tighten the fixing.
1. Captive nut
2. Fixing
3. Rear light
