Rear Light – Removal
Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
Perform the following operations:
• Seat - Removal
• Battery - Removal
• Rear Mudguard - Removal
To prevent damage to the rear mudguard painting finish, place the mudguard on a
clean, flat surface which is covered with a soft cloth.
1. Remove the fixings securing the rear light to the left and right hand mudguard
carriers.
2. Remove the captive nut for the rear light centre fixing and remove the rear light.
1. Fixing (right hand side shown)
2. Captive nut
