Triumph Rocket 3 GT 2021 - Page 1297

1259
9. Tighten the M6 x 42 mm fixings to 7 Nm.
1. Fixings M6 x 20mm
2. Fixing M6 x 42mm
3. Starter motor cover
Perform the following operations:
• Battery Box - Installation
• Battery - Installation
• Seat - Installation
Rear Mudguard – Removal
Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
