Triumph Rocket 3 GT 2021 - Page 1298

1260
Perform the following operations:
• Seat - Removal
• Battery - Removal
• Passenger Seat Backrest - Removal
1. Detach the harness clip from the rear subframe front bridge.
2. Release the fixings and washers, remove the rear subframe front bridge.
1. Harness clip
2. Fixings
3. Front bridge
NOTICE
Note that at the rear of the phone storage box there are two locating lugs that fit into
the rear subframe bridge for installation.
Note the routing of the USB harness for installation.
3. Remove the fixings.
