9. Fit the flyscreen mounting to the front subframe and tighten the fixings to 5 Nm.
1. Twist grip position sensor connector
2. Handlebar sub harness connectors
3. Cable tie (one of two shown)
4. Flyscreen mounting fixings
10. Check the headlight operation and the beam settings, rectify as necessary.
