7. Connect the direction indicator harnesses to the main harness.
1. Right hand direction indicator connectors
2. Left hand direction indicator harnesses
3. Red tape (right hand side only)
8. Connect the two handlebar subharness connectors and the twist grip position sensor
connector to the main harness.
9. Secure the harness to the underside of the flyscreen mounting with two cable ties, as
noted for removal.
10. Fit the flyscreen mounting to the front subframe and tighten the fixings to 5 Nm.
