Triumph Rocket 3 GT 2021 - Page 1414

1374
3. Connect the rear direction indicator electrical connectors and route the harnesses as
noted for removal.
4. Fit the upper cover to the indicator mounting. Make sure the locating lug on the
upper cover locates into its slot on the lower mounting.
5. Fit new M5 x 14mm fixings and tighten to 3 Nm.
6. Fit new M5 x 12mm fixings and tighten to 1 Nm.
1. Fixings (M5 x 14 mm)
2. Fixings (M5 x 12 mm)
3. Upper cover
4. Slot on lower cover
5. Lug on upper cover
1. Right hand direction
indicator connectors
2. Red tape
3. Left hand direction
indicator connectors
