114
Removal
Perform the following operations:
• Fuel Pump Assembly - Removal
NOTICE
Note the orientation of the hose bracket arall hose retaining clips for installation.
1. Release the fixing and remove the hose bracket from the fuel pump bracket.
1. Fixing
2. Hose bracket
NOTICE
Prior to removing the filter, note the direction of the arrow on the side of the filter. The
arrow should point away from the fuel pump, towards the pressure regulator.
2. Remove and discard the two fuel filter cable ties.
3. Release clip securing the fuel hose to fuel outlet pipe.
4. Release the two fuel hose clips from either side of the fuel filter.
