3. Connect the licence plate light electrical connector and route the harness as noted
for removal.
1. Licence plate light connector
4. Fit the upper cover to the indicator mounting. Make sure the locating lug on the
upper cover locates into its slot on the lower mounting.
5. Fit new M5 x 14mm fixings and tighten to 3 Nm.
6. Fit new M5 x 12mm fixings and tighten to 1 Nm.
1. Fixings (M5 x 14 mm)
2. Fixings (M5 x 12 mm)
3. Upper cover
4. Slot on lower cover
5. Lug on upper cover
