Triumph Rocket 3 GT 2021 - Page 1428

1388
5. With the instruments assembly positioned onto the instruments riser, make sure the
lug on the right hand side of the mounting is positioned between the two adjuster
stops on the riser.
1. Lug
2. Adjuster stops
3. Instruments riser
6. Fit the fixings and tighten to 5.5 Nm.
1. Fixing (left hand side shown)
2. Instruments
