1398
2. Fit the side stand assembly to the crankcase and tighten the fixings to 41 Nm.
1. Fixings
2. Side stand assembly
3. Route the side stand harness as noted for removal and connect to the main harness.
4. Fit the starter motor cover tighten the M6 x 20 mm fixings to 9 Nm.
5. Tighten the M6 x 42 mm fixings to 7 Nm.
1. Fixings M6 x 20mm
2. Fixing M6 x 42mm
3. Starter motor cover
